Subframe spacers kit correct for CV joints angles. Better CV joint Geometry will increase life span. Spacer kit includes spacers for Engine Crossmember, Transmission, Carrier bearing, Differential hanger and rear Differential. Install time 10-12 hours min.
*LEAD TIME: Not posted. Don't ask.
For extreme strength and reliability, we Laser cut and form 1/4" Steel with added gussets. All holes are Laser cut for accurate fitment.
To maintain good cv joint angles when exceeding 2.5" of lift subframe spacers will be needed to keep the cv joints within their limitations. Goal is to keep cv joints within 2-2.5" over factory angle.
Trailing Arm Spacers
Trailing arm spacers are not included in this kit.
These sets do not come powder coated. Raw steel will require painting or coating..
All Metric Grade 10.9 Zinc Hardware is included in the kits!
- Steering shaft extension included in the kit
- Longer pitch mount induced in the kit
- Radiator hose extension included
Upper radiator hose needs modification, cut and sleeve with the provided extension.. Steering shaft must be drilled and installed with the new spacer. Shift linkage modification required for manual transmission, not included. Air box may need modification. Other requirements may be necessary for proper function that are not listed. Front U support under the front, spacers are not provided. Recommend rebuilding.
